Raw Materials
The body, cab, frame and boom of a telescoping boom rough terrain forklift are normally manufactured by a forklift manufacturer. The most popular material for these subassemblies is steel, because of its incredible strength. At times aluminum or steel forgings are utilized too. It is common for non-metallic materials such as nylon plastic blocks to be used as guides in the boom assembly. The other components are normally bought as finished products and the lift truck maker installs them.
Pre-assembled bought products can include some of the following: transmission, seat, engine, axles, tires, wheels and hoses, backup-alarm, lights, hydraulic cylinders and gauges. Usually, certain materials like for instance the lubricants and hydraulic fluid and fuel are bought in bulk. These liquids are added as required once the machine is assembled and has passed the rigorous testing sessions.
Design
The common design which is most standard of telescoping boom rough terrain forklifts is a long and narrow design that has a set of wheels at the front of the unit and another set located towards the back of the machinery. The boom portion of the model is mounted at the forklift's rear off of a pivot feature that is raised a few feet above the frame's level. Normally, the cab is mounted on the frame structure's left-hand side. Normally, the bottom half of the cab is low and located between the tires. The hydraulic fuel tank and the fuel tank are mounted on the right-hand side, opposite the cab. Along the center-line of the vehicle, the transmission and the engine are mounted within the frame.
Beyond this basic configuration, different manufacturers have contributed to their own unique design. On the market these days, there are many different options available. Certain units of forklifts utilize a single hydraulic cylinder in order to elevate the boom, and other units utilize 2 cylinders. Several models use a side-to-side hydraulic frame leveling capability. This feature allows the frame to tilt up to 10 degrees relative to the axles so as to enable the machine to compensate for extreme axle articulation. This is used for example, when the tires on one side of the forklift are situated down in a rut and the tires on the other side of the equipment are up, located on a mound of dirt.
One more popular design feature includes fork attachments which are capable of swinging up to 45 degrees both right and left, in order to enable precise load placement.
