The forklift's turning radius is also referred to as the turning circle, that is essential information for the driver to have. It gives the operator the knowledge of how much space is required to turn the forklift around. Like for instance, a tighter turning radius allows the machinery to successfully work in crowded areas and restricted places, therefore improving the forklift's maneuverability. Drivers who are not aware of this measurement can cause damage to the property or to the machinery.
Make the necessary steering geometry alignment corrections before testing the turning radius. The test should start with an operator trainer helping inside the cab where they could assist to control the equipment's functions. Another individual on the ground uses a hose or a spray bottle to wet the inside and outside of the model's wheels. Then, drive the machinery in a complete circle with the wheels turned to the maximum angle. Repeat the procedure once and if necessary, continue to wet the wheels.
When this measurement test has been done, measure the watermarks left by the tires utilizing a tape measure, from the midpoint of the tire mark to a similar point across the circle's diameter. For the outside turning diameter, measure the watermark left by the outside tires from one side of the circle to the circle's opposite side. You could establish the inside turning radius by stretching the tape measure across the circle left by the inner tires. Then, divide these numbers in 2 to be able to establish the turning radius. Be certain to note that the turning center is the midpoint of the diameter of the circle.
Drop a plumb line from the extreme outside radial extension on the machine in order to determine the wall-to-wall turning diameter. When this is completed, next find the point on the pavement directly beneath. This point to the turning center indicates the clearance radius of the vehicle. As a rule, wall-to-wall turning diameter is two times the clearance radius of the vehicle.
