Kinds of Jib Cranes
The trolley hoist on a horizontal load-bearing boom are key features on Jib cranes. The boom is secured to a vertical mast which measures up to 20 feet long. Jib cranes can transport loads between any areas within the boom's arc of rotation. Light duty models are utilized inside warehouses and factories for loads weighing up to 5 tons. The website BestJibCranes.com features the major jib crane types as being either free-standing, wall-mounted or mast mounted.
Free Standing
Free-standing jib cranes could stand alone not requiring support from the building structure. The horizontal boom in this situation is attached to a pivoting vertical column that is solidly anchored to the floor of the building. This type of jib crane can rotate a full 360 degrees and needs a foundation made of either steel or concrete.
Mast-Type
The mast-type jib cranes feature a vertical column that is supported by pivot points at the top and the bottom that are connected to the floor of the building and the overhead steel structure. These jib-cranes offer 360 degrees of rotation with the advantage of not needing the massive foundation required for free-standing units.
Wall Mounted
The wall-mounted jib cranes offer a horizontal boom which is connected to the wall of a building rather than the typical vertical column. These machinery are ideal in places where the full 360 degree rotation is not needed and provide up to 200 degrees of rotation.
Depending on how the boom is supported, there are two model varieties. One kind uses a tie rod from above the boom that is connected to the wall. The other type supports the boom from below by utilizing a cantilever brace that is also attached to the wall.
