Due to the way they specifically work, hydraulic truck cranes are different from other crane types. Rather than using a winch in order to wind up cables to provide the lifting force, hydraulic cranes utilize oil instead. Because oil is a type of fluid that retains its volume, it is incompressible. Hence, this means it is amongst the most ideal kinds of fluids for pushing pistons towards the direction the force is going to be exerted.
The hydraulic pump generates a pressure which moves the piston. This particular action is maneuvered by the operator utilizing the controls within his cab. Normally, hydraulic truck cranes utilize a pump that has 2 gears.
Because the actual crane itself is mounted on a truck, it could travel numerous distances from site to site and there is little dismantling involved. The truck crane has one engine which can control both the truck and the crane.
Other Parts
Boom Telescope: The boom telescope enables the boom to extend or retract because of hydraulics.
Jib: The jib is a latticed structure which extends from the boom.
Boom Swing: The boom swing is a big ball or roller that is attached to the carrier. It could swing 360 degrees in both directions. Hydraulic devices provide swings at various speeds and control the swing in order to rotate the turntable gearbox.
Outrigger: Outriggers are units which cranes would use to maintain its balance. It uses hydraulics to lift the truck.
Load Movement Indicator: In order to alert the operator that maximum weight is approaching, the load movement indicator's lights flash.
Pump: The pump's purpose is to steer the outrigger.
Steel Cables: Steel reinforced cables run through the jib and the boom. They can generate up to 6350 kg or 14,000 lbs.
Boom Elevation: The crane's boom ascends with the use of double hydraulic cylinders which could be raised and lowered.
Rotex Gear: The rotex gear is operated by hydraulics and located underneath the cab. It allows the boom to swivel on this gear.
